• Switching ：25mA at 24VDC
• Non-Switching ：100mA at 50VDC
• Initial : 50mΩ Max
• After life 100mΩ Max
• Insulation Resistance ：100mΩ Max, Min at 100VDC
• Dielectric Strength : 300VAC for 60 seconds
• Switch Capacitance ：5pF Max at 1MHz
• Operation Temperature : -30°C to +85°C
• Storage Temperature : -40°C to +85°C
• Operation Force : 500gf Max
• Mechanical Life : 2000 cycles operations
|
 |
   |
| Part Number | Non-Switching | Intial | After life | Insulation Resistance | Dielectric Strength | Operation Temperature | Operation Force | Mechanical Life | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| RPH | 100mA at 50VDC | 50mΩ Max | 100mΩ Max | 100mΩ Max,100VDC | 300VAC for 60 seconds | -30℃ to +85℃ | 500gf Max | 2000 cycles | 暫無 |
| RPM | 100mA at 50VDC | 50mΩ Max | 100mΩ Max | 100mΩ Max,100VDC | 300VAC for 60 seconds | -30℃ to +85℃ | 500gf Max | 2000 cycles | 暫無 |
